Ruixu Server Rack Battery - Daisy Chain, Bracket Rack

by Ruixu
SKU RX-10kWH-DC-C
Save up to $929.60 Save $464.80
Original price $2,668.00
Original price $2,668.00 - Original price $5,336.00
Original price $2,668.00
Current price $2,203.20
$2,203.20 - $4,406.40
Current price $2,203.20
🚚 Fast Delivery Times

💰 Lowest Price Guaranteed

🛡️Premium Authorized Ruixu Dealer - Warranty Included

🧑🏻‍💼Post-Purchase Lifetime Customer Support

❓Questions? Talk to Experts (916)-999-9937
 More payment options

Have Questions? 📞Call or Text (916)-999-9937 (10am-10pm EST - Daily)

Description

Ruixu Server Rack Battery - Daisy Chain, Bracket Rack

RUiXU bracket rack is a specially designed accessory that allows you to stack up to nine Ruixu RX-LFP48100 lithium batteries vertically in a compact and stable configuration. The RUiXU bracket rack is the perfect solution for homeowners and businesses who want to enjoy the benefits of a reliable, scalable, and cost-effective energy storage system.

For the self-heating server rack battery option, click here!

RUiXU Server Rack Battery Optional Installation Method -Bracket Racks - Daisy Chain Connection

  • Flexibility & Stackable
  • 10kWH-20kWH,Max 4 Stacks
  • A rack can be added as needed it

Modular: Support up to 32 units in parallel, scale from 5 kWh to 160 kWh configuration without external controller.

Inverter Protocol Choosing: Use DIP address to set the RS485 baud rate and inverter protocol choosing

Communications:

  • Canbus: Victron, SMA, Studer Innotec, Sofar, Solark, Solis, Goodwe, Deye, Growatt, SAJ, LUXPOWER, Megarevo, INVT, Sermatec, TBB, MUST, Sunsynk, Schneider
  • RS485: MPP, Voltronic, RCT, Alpha outback

SPECIFICATIONS:

Nominal voltage 51.2V
Nominal capacity 100Ah
Nominal energy 5.12kWh
Usable energy 4.92kWh
Operating voltage range 44.8V-56.0V
Charge voltage 56V
Float voltage 54.6V
Recommended charge current 50A
Max. charge current 70A
Recommended discharge current 50A
Max. discharge current 100A
Communication RS485 / CAN
Peak discharge current 101~119A @ 5mins
IP rating IP20
Cycle life ≥6000 cycles @90%DOD
Net weight 103.6lb
Dimension (W*H*D) 18.9*5.2*18.1 inches
Cell type Lithium-iron phosphate (LiFePO4)
Design life 15 years
Operation temperature -10~50°C (14~122°F)
Storage temperature -10~45°C (14~113°F)
Relative humidity 5%~90% No condensation
Install altitude ≤4000m
Install location Indoor
Installation Wall mounted / Floor mounted / Stack / Rack mounted
Certification CE / IEC62619 / UN1973 / UN38.3

GUIDE:

User Manual
