Ruixu Battery Optional Installation Method Bracket Rack - Flexibility & Stackable

Ruixu Battery Optional Installation Method Bracket Rack - Flexibility & Stackable

by Ruixu
SKU RX-10kWH-BR-C
Save up to $2,105.60 Save $478.80
$2,808.00
$2,808.00 - $12,146.00
$2,808.00
$2,329.20
$2,329.20 - $10,040.40
$2,329.20
🚚 Fast Delivery Times

💰 Lowest Price Guaranteed

🛡️Premium Authorized Ruixu Dealer - Warranty Included

🧑🏻‍💼Post-Purchase Lifetime Customer Support

❓Questions? Talk to Experts (916)-999-9937
 More payment options

Have Questions? 📞Call or Text (916)-999-9937 (10am-10pm EST - Daily)

Description

Ruixu Battery Optional Installation Method Bracket Rack - Flexibility & Stackable

The RUiXU Bracket Rack is a modular and space-efficient installation solution for RX-LFP48100 server rack batteries. Designed for flexibility and vertical stacking, it's perfect for homeowners and businesses seeking scalable and cost-effective energy storage.

For Self-Heating Battery Optional Installation Method Battery Rack, click here!

FEATURES:

  • Flexible & Stackable Design
    • Stack up to 9 RX-LFP48100 batteries vertically
    • Expandable from 10kWh to 45kWh with a maximum of 9 units
    • Additional racks can be added as needed
    • RUiXU Busbar included
  • Modular Capacity
    • Supports up to 32 units in parallel
    • Scale your system from 5kWh to 160kWh
    • No external controller required
  • Smart Configuration
    • Use DIP address settings for selecting RS485 baud rate and inverter protocol

INCLUDES:

(With Each Battery)

  • (1) RUiXU 48V Server Rack Battery (RX-LFP48100)
  • (1) RJ45/CAT5e Patch Cable
  • (1) Ground Cable
  • (1) Set of Parallel 4AWG Cables

Optional Accessories (Sold Separately)

SPECIFICATIONS:

Parameters RX-LFP48100
Nominal voltage 51.2V
Nominal capacity 100Ah
Nominal energy 5.12kWh
Usable energy 4.92kWh
Operating voltage range 44.8V-56.0V
Charge voltage 56V
Float voltage 54.6V
Recommended charge current 50A
Max. charge current 70A
Recommended discharge current 50A
Max. discharge current 100A
Communication RS485 / CAN
Peak discharge current 101~119A @ 5mins
IP rating IP20
Cycle life ≥6000 cycles @90%DOD
Net weight 103.6lb
Dimension (W*H*D) 18.9*5.2*18.1 inches
Cell type Lithium-iron phosphate (LiFePO4)
Design life 15 years
Operation temperature -10~50°C (14~122°F)
Storage temperature -10~45°C (14~113°F)
Relative humidity 5%~90% No condensation
Install altitude ≤4000m
Install location Indoor
Installation Wall mounted / Floor mounted / Stack / Rack mounted
Certification CE / IEC62619 / UN1973 / UN38.3
Communications
Canbus Victron, SMA, Studer Innotec, Sofar, Solark,Solis, Goodwe,
Deye, Growatt, SAJ, LUXPOWER, Megarevo, INVT, Sermatec,
TBB, MUST, Sunsynk, Schneider
RS485 MPP, Voltronic, RCT, Alpha outback

GUIDE:

User Manual

Specification Sheet
