Take control of your comfort with the MRCOOL DIY 5th Gen Multi-Zone Mini Split System — the simplest and most affordable way to enjoy powerful, energy-efficient heating and cooling without hiring a pro.
-
Two Rooms, Perfect Comfort: Heat or cool two spaces — one up to 150 sq. ft. and another up to 1,500 sq. ft. — each with independent temperature control for personalized comfort.
-
Truly DIY-Friendly: Skip the costly installations — no HVAC license or special tools required. If you can use basic hand tools, you can do it yourself.
-
No-Hassle Setup: Includes pre-charged Quick-Connect® line sets, eliminating the need for refrigerant handling or vacuuming. Just connect, tighten, and enjoy instant comfort.
-
Year-Round Savings: With up to 21.8 SEER2 cooling efficiency and 10 HSPF2-4 heating performance, this system delivers impressive energy savings and comfort all year long.
-
Built for Every Season: Stay warm even in the coldest winters — dependable heating performance works down to -13°F.
-
Strong Warranty Protection: Backed by a 7-Year Compressor Replacement Warranty and 5-Year Parts Coverage for lasting peace of mind.
No matter the season, the MRCOOL DIY Mini Split keeps your home perfectly comfortable while helping you save on energy costs. Smart. Simple. Affordable.
WHAT YOU GET:
MRCOOL DIY® 5th Gen 48,000 BTU 6-Zone Mini Split Condenser 230V (DIY-MULTI6-48HP230D-O)
MRCOOL DIY® 5th Gen 6,000 BTU Multi-Zone Mini Split Air Handler 230V (DIY-06-HP-WMAH-230D25-O)
MRCOOL DIY® 5th Gen 36,000 BTU Multi-Zone Mini Split Air Handler 230V (DIY-36-HP-WMAH-230D25-O)
-
PRE-CHARGED LINE SETS x 2
- REMOTE CONTROL x 2
NOTE: Need different line set lengths? Click here to add them as add-ons.
SPECIFICATIONS:
| SYSTEM OVERVIEW |
| System Type |
Ductless Mini Split Air Conditioner & Heat Pump |
| Zones |
2 |
| Capacity |
Total: 42,000 BTU
Zone 1: 6,000 BTU
Zone 2: 36,000 BTU
|
| Coverage Area |
Total: 1,650 sq. ft.
Zone 1: 150 sq. ft.
Zone 2: 1,500 sq. ft.
|
| Refrigerant |
R-454B |
| Line Sets Included |
2 x Pre-Charged Line Sets |
| Warranty |
7 Years Compressor
5 Years Parts
|
| OUTDOOR UNIT (48K) x 1 |
| Model |
DIY-MULTI6-48HP230D-O |
| Dimensions |
37.48" W x 16.34" D x 52.48" H |
| Cooling Capacity |
43,000 BTU |
| SEER2 |
21.8 |
| EER2 |
12.0 |
| Heating Capacity |
48,000 BTU |
| HSPF2-4 |
10.0 |
| HSPF2-5 |
7.8 |
| Outdoor Noise Level |
64.0 dB(A) |
| Outdoor Operating Temperature |
Cooling: -13°F – 122°F
Heating: -13°F – 75°F
|
| Voltage |
208–230V |
| Phase |
1 |
| Cycle |
60Hz |
| Min Circuit Ampacity |
40.0A |
| Max Fuse Breaker |
45.0A |
| Weight |
223.77 lbs |
| Certifications |
ENERGY STAR Certified
AHRI Certified
UL Listed
ETL Listed
|
| INDOOR UNIT (6K) x 1 |
| Model |
DIY-06-HP-WMAH-230D25-O |
| Dimensions |
31.57" W x 7.44" D x 11.69" H |
| Mounting Type |
Wall |
| Cooling Capacity |
6,000 BTU |
| Heating Capacity |
6,000 BTU |
| Coverage Area |
100 to 150 sq. ft. |
| Liquid Line Size |
1/4" |
| Suction Line Size |
3/8" |
| Modes |
Auto Mode: Automatically selects heating or cooling based on the room's temperature.
Cool Mode: Lowers the room temperature to your desired setting.
Heat Mode: Raises the room temperature to your desired setting.
Fan-Only Mode: Circulates air without heating or cooling.
Dry Mode (Dehumidification): Reduces humidity levels in the room.
Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
|
| Weight |
24.47 lbs |
| INDOOR UNIT (36K) x 1 |
| Model |
DIY-36-HP-WMAH-230D25-O |
| Dimensions |
49.57" W x 11.1" D x 14.25" H |
| Mounting Type |
Wall |
| Cooling Capacity |
36,000 BTU |
| Heating Capacity |
36,000 BTU |
| Coverage Area |
1,001 to 1,500 sq. ft. |
| Liquid Line Size |
3/8" |
| Suction Line Size |
5/8" |
| Modes |
Auto Mode: Automatically selects heating or cooling based on the room's temperature.
Cool Mode: Lowers the room temperature to your desired setting.
Heat Mode: Raises the room temperature to your desired setting.
Fan-Only Mode: Circulates air without heating or cooling.
Dry Mode (Dehumidification): Reduces humidity levels in the room.
Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
|
| Weight |
48.72 lbs |
