Bluetti - AC200MAX Expandable Power Station - 2,200W 2,048Wh
BLUETTI first expandable power station-AC200MAX with 2,048Wh LiFePO4 cells and 2,200W pure sine wave inverter.
Your mobile power center at home or on the way.
-
SMALL CHANGE, HUGE LEAP
The first modular, expandable Bluetti power station. Packed with an astonishing 2048Wh ultra-durable LFP cells and a 2,200W full power pure sine wave inverter, the AC200MAX can be your mobile recharge center off-the-grid or on the way.
LESS TO SPEND, MORE TO LOVE
Struggling between power and flexibility? We got you covered! With two expansion ports, The AC200MAX welcomes up to two BLUETTI B230’s(2048Wh each) or B300(3072Wh each) battery modules, connecting of which can boost the total capacity to a staggering 8192Wh!
GET CHARGED IN ANYWAY YOU PREFER
The AC200MAX allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours! Further more, every Bluetti battery module has their own input port for AC adapters, you’ll get another 500W of input capability with every module added (Up to two for the AC200MAX).
INCOMPARABLE OUTLET VERSATILITY
With AC200MAX’s 16 outlets, you get to run all your needs simultaneously without breaking a sweat. And especially for the RV enthusiasts the AC200 MAX has a specially designed built-in 30A NEMA TT-30 outlet and a 12V 30A super powerful DC outlet.
- 1400W Max. Fast Dual Charging (Solar + AC Adapter)
- Smart Control & Monitor in BLUETTI App
Capacity:
2,048Wh (51.2V, 40Ah)
Type:
LiFePO4 (Lithium Iron Phosphate)
Life Cycles:
3,500+ Cycles to 80% Original Capacity
Shelf-life:
Recharge to 80% Every 3-6 Months
Management System:
MPPT Controller, BMS, etc
AC Outlets:
4 x 120V/20A Outlets
1 x 120V/30A NEMA TT-30
2200W In Total
Inverter Type:
Pure Sine Wave
USB-C Port:
1 x 100W Max.
USB-A Port:
2 x 5V/3A USB-A
2 x 18W USB-A
12V DC Outlets:
1 x 12V/30A (RV Outlet)
1 x 12V/10A (Car Outlet)
2 x 12V/10A DC 5521 (5.5mm Outlet)
*All Regulated.
Wireless Charging Pad:
2 x 15W Max. (For Each)
Solar Input:
900W Max., VOC 10-145VDC, 15A
Car Input:
12/24V from Cigarette Lighter Port
Max Input:
1,400W, with AC+Solar Input
AC Adapter (500W):
≈5.5~6 Hours
Solar (900W):
≈3~3.5 Hours (With prime sunshine, ideal orientation and low temperature)
12V/24V Car Outlet (100W/200W):
≈10 or 20 Hours
AC Adapter + Solar (1400W):
≈2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature)
Dual AC Adapters (1000W):
≈3~3.5 Hours (Extra adapter is REQUIRED)
240V Split Phase Bonding:
No. Need 240V power source.
Scalability:
Expandable w/ Up to 2 x B230 or 2 x B300
Pass-through Charging:
Yes
Dimensions (LxWxD):
16.5 x 11 x 15.2in ( 42 x 28 x 38.65cm)
Operating Temperature:
-4-104℉ (-20-40℃)
Storage Temperature:
14-113℉ (-10-45℃)
Certifications:
UL2743, UKCA, TELEC, RCM, FCC ID, CE, PSE, NTC
Warranty:
48 Months (Learn more about BLUETTI warranty policy)
Capacity:
2,048Wh (51.2V,40Ah)
Type:
LiFePO4 (Lithium Iron Phosphate)
Life Cycles:
3,500+ Cycles to 80% Original Capacity
Shelf-life:
Recharge to 80% Every 3-6 Months
Management System:
MPPT Controller, BMS, etc.
USB-C Port:
1 x 100W Max.
USB-A Port:
1 x 18W USB-A
12V DC Outlets:
1 x 12V/10A (Car Outlet)
AC Adapter Input:
500W Max.
Solar Input:
500W Max., VOC 12-60VDC, 10A (Via BLUETTI D050S)
Car Input:
12/24V from Cigarette Lighter Port (Via BLUETTI D050S)
Lead-acid battery:
12/24V from Cigarette Lighter Port (Via BLUETTI D050S)
AC Adapter (400W):
≈5.5~6 Hours
Solar (500W):
≈4.5~5 Hours (With prime sunshine, ideal orientation and low temperature)
12V/24V Car Outlet (100W/200W):
≈10 or 20 Hours
Compatibility:
AC200Max(Original Expansion), AC200P/EB150/EB240 (DC-DC Connection via D050S)
Pass-through Charging:
Yes
Dimensions (LxWxD):
16.5 x 11 x 8.9in ( 42 x 28 x 22.75cm)
Operating Temperature:
32°F-104°F (0-40°C)
Storage Temperature:
-4-104℉(-20-40℃)
Certifications:
UL2743, UKCA, RCM, PSE, FCC, CE
Warranty:
48 Months (Learn more about BLUETTI warranty policy)
![](https://www.bluettipower.com/cdn/shop/files/p090a_c14932fe-f2fc-4e33-bdb4-685924f47ee7.png?v=1676510926&width=1200)
FAQS
Q1: How many B230 or B300 battery module can be hooked up with the AC200/P?
A: Up to two B230 or B300, one via the solar input port by a converter cable, and another one via the AC adapter inlet (Require the BLUETTI D050S - DC charging enhancer, sold separately).
Q2: Can the B230 battery module be used alone?
A: Yes. B230 has a 100W USB-C, a USB-A and a 12V DC output ports, the battery module can work flawlessly when standalone.
A: B230 can be recharged by:
- 1. 500W AC adapter (Sold separately)
- 2. Car cigarette lighter output or solar panels (Require the BLUETTI D050S - DC charging enhancer, sold separately).
- Notice: There is only one inlet on the battery module, so it cannot be charged by more than one charge method simultaneously.
Q4: Does AC200MAX support split phase bonding?
Q5: Can AC200MAX be remotely controlled via APP?
- A: ou can control the AC200 MAX via APP or touchscreen. But APP only can be connected via Bluetooth.
Q6: How many B230 or B300 battery module can be charged with AC200MAX?
- A: Up to two B230’s or B300 battery modules
Q7: What are the charging methods for AC200MAX?
1. Wall outlet (AC adapter): MAX.500W, fully recharge in 4.6~5.1hrs.2. Dual AC Adapters: MAX.1000W, fully recharge in 2.5~3.0hrs.3. Solar Panels: MAX.900W, Open circuit voltage range: 10V~145V; fully recharge in 2.8~3.3hrs. (Doesn’t work with roof solar array with total Voc higher than 145V)4. Solar Panels & Wall Outlet simultaneously: MAX.1400W (500W from AC adapter, 900W from solar panels), fully recharge in 2~2.5hrs5. 12V/24V Car Cigarette Lighter6. 12V/24V lead-acid Battery7. EV Charging Station (EV adapter sold separately)8. Generator9. BLUETTI Wind Turbine (In progress)
Q8: Does AC200MAX have UPS function?
Q9: Can AC200MAX be recharged with solar panels and wall outlet simultaneously or dual AC adapters?
Q11: Can I use third party solar panel and what conditions need to be met?
- A: Yes, you can. The solar array must meet the following conditions:
- 1. Total open circuit voltage(Voc) falls in the range of 10-145V/MAX.12A, MC4 connectors
