Big Battery 24V EAGLE 2 With Heater - LiFePO4 - 64Ah - 1.63kWh Battery
2ND GENERATION POWER TAKES FLIGHT! Introducing Big Battery 24V EAGLE 2 With Heater. This battery embodies the reliability and durability you’ve come to expect from BigBattery solutions, packing Tier 1 LFP cells in a compact, GC2 form factor. This energy-dense design allows for effortless installations in your RVs, camper vans, scissor lifts, or other industrial equipment, and the Big Battery 24V EAGLE 2 With Heater serves as a mirror-image replacement for any stock T-105 lead-acid battery.
But the Big Battery 24V EAGLE 2 With Heater provides so much more than efficient, long-lasting lithium power storage. This battery comes standard with advanced features that enhance the safety and visibility of your power. Not only does the EAGLE 2 come equipped with a LED capacity meter on the top of the unit, but also supports CANBus communication protocols, so you can always monitor the status and performance of your battery system. Plus, the EAGLE 2 is IP67-rated for comprehensive protection against dust, water, and other contaminants while you’re cruising around the campsite or warehouse.
But that’s not all. The Big Battery 24V EAGLE 2 With Heater was designed to support your applications through every season. Whether you’re going boondocking in the heat of summer, or working at the warehouse or job site in the dead of winter, the EAGLE 2’s advanced BMS supports a wide temperature operating range, and a self-heating function ensures that you never have to put your vacation or work day on pause due to unreliable power. Quit worrying about your power and get back to working hard and playing harder when you equip your vehicle with the all-new EAGLE 2 from BigBattery. Shop the 24V EAGLE 2 & EAGLE 2 Kits today!
What's Included
- (1) Eagle 2 Carrying Handle
- (1) Eagle 2 CAN Comm Cable
- (1) Parallel CAN Comm Cable
- (2) M8 Nuts & Screws
Key Features
- GTIN-12 (U.P.C.): 850061252197
- System Voltage: 24V
- Nominal Voltage: 25.6V
- Chemistry: LiFePO4
- kWh Capacity: 1.63kWh
- Ah Capacity: 64Ah
- Charging Voltage Range: 27.8 - 29V
- Max Charge Voltage: 29.2V
- Operating Voltage Range: 24 - 28.8V
- Suggested Low Voltage Cutoff: 24 - 25.4V
- BMS Cutoff Range: 21 - 23.5V
- Cell Configuration: 8S
- Max Continuous Discharge Current: 100A
- Max Continuous Power: 2560W
- Max Discharge Peak Current: 200A (Max 5 seconds)
- Max Charge Current: 64A
- Charge Temperature Range: -4°F - 131°F (-20°C - 55°C)
- Discharge Temperature Range: -4°F - 140°F (-20°C - 60°C)
- Optimal Discharge Temperature Range: 59°F - 95°F (15°C - 35°C)
- Storage Temperature Range: 23°F - 95°F (-5°C - 35°C) (Max 3 months)
- 32°F - 77°F (0°C - 25°C) (Max 12 months)
- Weight: 38 lb (17.2 kg)
- Depth: 7.1 in (180 mm)
- Width: 10.2 in (260 mm)
- Height: 10.8 in (274 mm)
- Max Connections: Up to (10) Parallel
- Protection Rating: IP67
- Communications: CANBus
- Self-Heating: Yes
Downloads
Warranty
10-Year Warranty Applied To Batteries Only
Additional Information
Features:
- Advanced BMS with automatic cell balancing
- Lithium-ion chemistry (LiFePO4/LFP)
- Easy connection to a larger power system
- Expandable system with easy parallel connections
- Multiple layers of safety and battery protections
- Built-in self-heating system
- mpact & vibration resistant
- P-67 protection rating
- Good insulation performance
- Durable ABS construction
- Standardized M8 bolt connectors for cable connections
- Smart controller box
- Parallel communication
- CANBus parallel communications (FEAGL-24016-G2-0CH & FEAGL48016-G2-0CH only)
- LED SoC meter
- GC2 form factor
Designed For 24V Applications
- T-105 EXACT REPLACEMENT
- LIGHT INDUSTRIAL EQUIPMENT
- FLOOR SWEEPERS
- FLOOR SCRUBBERS
- PALLET JACKS
- SCISSOR LIFTS
- LIGHT TOWERS
- CLASS A, B, & C RVs
- CAMPER VANS
- EMERGENCY BACKUP
- INCLUDES INTERNAL WARMERS
- OPERATES IN SUB-ZERO TEMPS
